LM317

adjustable 3-terminal positive voltage regulator, TO, 1.2V to 37V, Current limit constant, 80 dB ripple rejection, two external resistors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.12~0.15 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.12~0.15

PartNumber:: LM317

Brand:: National Semiconductor - NS | Pack: TO | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Ellen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-31

From Other Seller

Part Number:LM317
US $0.12 - 0.15
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
IRFP260N

US $1.30 - 4.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM317 is an adjustable 3-terminal positive voltage regulator. It is capable of supplying in excess of 1.5A over a 1.2V to 37V output range. The LM317 is exceptionally easy to use and require only two external resistors to set the output voltage. Further, both line and load regulation are better than standard fixed regulators. Also, the LM317 is packaged in standard transistor packages which are easily mounted and handled.

Parametrics

LM317 absolute maximum ratings: (1)Power Dissipation: Internally Limited; (2)Input-Output Voltage Differential: +40V, -0.3V; (3)Storage Temperature: -65 to +150℃; (4)Lead Temperature, Metal Package (Soldering, 10 seconds): 300℃; (5)ESD Tolerance: 3 kV.

Features

LM317 features: (1)Guaranteed 1% output voltage tolerance; (2)Guaranteed max. 0.01%/V line regulation; (3)Guaranteed max. 0.3% load regulation; (4)Guaranteed 1.5A output current; (5)Adjustable output down to 1.2V; (6)Current limit constant with temperature; (7)P+ Product Enhancement tested; (8)80 dB ripple rejection; (9)Output is short-circuit protected.
