Product Summary
The BSP752T is a smart power high-side-switch. The BSP752T N channel vertical power FET with charge pump, ground referenced CMOS compatible input, monolithically integrated in Smart SIPMOS technology. The BSP752T provides embedded protective functions.
Parametrics
BSP752T absolute maximum ratings: (1)Supply voltage Vbb: 52 V; (2)Supply voltage for full short circuit protection Vbb(SC): 50; (3)Continuous input voltage VIN: -10 to +16; (4)Load current (Short - circuit current, see page 5) IL: self limited A; (5)Current through input pin (DC) IIN: ± 5 mA; (6)Operating temperature Tj: -40 to +150 ℃; (7)Storage temperature Tstg: -55 to +150; (8)Power dissipation 1) Ptot: 1.5 W.
Features
BSP752T features: (1)Overload protection; (2)Current limitation; (3)Short circuit protection; (4)Thermal shutdown with restart; (5)Overvoltage protection (including load dump); (6)Fast demagnetization of inductive loads; (7)Reverse battery protection with external resistor; (8)CMOS compatible input; (9)Loss of GND and loss of Vbb protection; (10)ESD - Protection.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 BSP752T |
Infineon Technologies |
Power Switch ICs - Power Distribution DSO-8-6 |
Data Sheet |
|
|
||||||||||||
