Product Summary

The OP282GS is a dual/quad low power, high speed JFET operational amplifier. The OP282GS dual and quad operational amplifier features excellent speed at exceptionally low supply currents. Slew rate exceeds 7 V/ms with supply current under 250 mA per amplifier. The unity gain stable amplifier OP282GS have a typical gain bandwidth of 4 MHz. The JFET input stage of the OP282GS insures bias current is typically a few picoamps and below 500 pA over the full temperature range. Offset voltage is under 3 mV for the dual and under 4 mV for the quad.

Parametrics

OP282GS absolute maximum ratings: (1)Supply Voltage: ±18 V; (2)Input Voltage: ±18 V; (3)Differential Input Voltage: 36 V; (4)Output Short-Circuit Duration: Indefinite; (5)Storage Temperature Range P, S Packages: –65℃ to +150℃; (6)Operating Temperature Range: –55℃ to +125℃; (7)Junction Temperature Range P, S Packages: –65℃ to +125℃; (8)Lead Temperature Range (Soldering, 60 sec): +300℃.

Features

OP282GS features: (1)High Slew Rate: 9 V/ms; (2)Wide Bandwidth: 4 MHz; (3)Low Supply Current: 250 mA/Amplifier; (4)Low Offset Voltage: 3 mV; (5)Low Bias Current: 100 pA; (6)Fast Settling Time; (7)Common-Mode Range Includes V+; (8)Unity Gain Stable.

Diagrams

OP282GS block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
OP282GS
OP282GS

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-98: $1.81
OP282GS-REEL
OP282GS-REEL

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-2500: $1.07
OP282GS-REEL7
OP282GS-REEL7

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-1000: $1.13
OP282GSZ
OP282GSZ

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-1: $1.95
1-10: $1.74
10-100: $1.43
100-250: $1.29
250-500: $1.16
500-1000: $0.98
1000-2500: $0.93
OP282GSZ-REEL
OP282GSZ-REEL

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-2500: $0.93
OP282GSZ-REEL7
OP282GSZ-REEL7

IC OPAMP JFET 4MHZ DUAL LP 8SOIC
Data Sheet
0-1000: $0.98
