Product Summary

The SI1555DL-T1-E3 is the complementary low-threshold MOSFET pair.

Parametrics

SI1555DL-T1-E3 absolute maximum ratings: (1)Drain-Source Voltage: 20V, -8V; (2)Gate-Source Voltage: ±12V, ±8; (3)Continuous Drain Current (TJ = 150℃): TA = 25℃,± 0.70, ±0.66, -0.60, -0.57A; (4)Continuous Drain Current (TJ = 150℃), TA = 85℃: ±0.50, ±0.48, -0.43, -0.41A; (5)Pulsed Drain Current: ±1.0A; (6)Continuous Source Current (Diode Conduction): 0.25, 0.23, -0.25, -0.23A; (7)Maximum Power Dissipation, TA = 25℃: 0.30, 0.27, 0.30, 0.27W ; (8)Maximum Power Dissipation,TA = 85℃: 0.16, 0.14, 0.16, 0.14W; (9)Operating Junction and Storage Temperature Range: -55 to 150℃.

Features

SI1555DL-T1-E3 features: TrenchFET Power MOSFET.

Diagrams

SI1555DL-T1-E3 pins

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SI1555DL-T1-E3
SI1555DL-T1-E3
Vishay/Siliconix
MOSFET 20/8 0.7/0.6
Data Sheet
0-1: $0.34
1-10: $0.22
10-100: $0.18
100-250: $0.15
